HM-1077
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 55.09 |
| L [ mm ] | 38 |
| W [ mm ] | 9.86 |
| G [ qty. ] | 6 |
| S [ mm ] | M16x1.5 |
| Clockwise | CW |
OE Number (22)
| OE Number | Producer |
|---|---|
| 20133 | LESTER |
| 20338 | LESTER |
| LRA03733 | LUCAS |
| 37300-2F000 | HYUNDAI |
| 37300-2F100 | HYUNDAI |
| 37300-2F300 | HYUNDAI |
| 37300-2F350 | HYUNDAI |
| 37300-2F800 | HYUNDAI |
| 37300-2R000 | HYUNDAI |
| 37300-2R100 | HYUNDAI |
| 37300-2R120 | HYUNDAI |
| 37300-2R510 | HYUNDAI |
| 37300-2U000 | HYUNDAI |
| 37300-2U200 | HYUNDAI |
| 37300-2U300 | HYUNDAI |
| 37321-2U000 | HYUNDAI |
| 2656070 | VALEO |
| 2606259 | VALEO |
| 2617532 | VALEO |
| FG15S108 | VALEO |
| FG15S029 | VALEO |
| FG15S034 | VALEO |
| Application | Brand |
|---|---|
| IX35 2.0 CRDi, 2.0 CRDi 4WD, 2.0 CRDi All-wheel Drive (110kW) 01/2010... | Hyundai |
| Santa F¨¦ II 2.0 CRDi, 2.0 CRDi 4x4 (110kW) 12/2010... | Hyundai |
| Santa F¨¦ II 2.0 CRDi, 2.0 CRDi 4x4 (145kW) 01/2009... | Hyundai |
| Tucson 2.0 CRDi, 2.0 CRDi All-wheel Drive (110kW) 01/2009... | Hyundai |
| Application | Brand |
|---|---|
| Sorento 2.0 CRDi, 2.0 CRDi 4WD (110kW) 01/2009... | Kia |
| Sorento 2.0 CRDi, 2.0 CRDi 4WD (145kW) 11/2009... | Kia |
Reference number (19)
| Ref Number | Producer |
|---|---|
| F-560201.XX | INA |
| 535021610 | LUK |
| ALP2451 | DAYCO |
| 354791 | IKA |
| 5593 | ZEN |
| 24-82119 | WAI |
| 28860 | ZNP |
| 21475 | JIASUN |
| 80580/80171 | NF |
| 37322-2F000 | HYUNDAI |
| 37322-2F001 | HYUNDAI |
| 37322-2E010 | HYUNDAI |
| 2605819 | VALEO |
| F032335262 | HC-CARGO |
| AFP3035 | AS |
| AFP3035INA | AS |
| 335262 | HC-CARGO |
| F56020101 | INA |
| F560201 | INA |
Frequently Asked Questions about HM-1077
Q: What OE numbers does HM-1077 replace?
A: The HM-1077 is a direct replacement for: LESTER 20133, LESTER 20338, LUCAS LRA03733, HYUNDAI 37300-2F000, HYUNDAI 37300-2F100, HYUNDAI 37300-2F300.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: INA F-560201.XX, LUK 535021610, DAYCO ALP2451, IKA 354791, ZEN 5593, WAI 24-82119.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
