HM-1170
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 53.4 |
| L [ mm ] | 39.2 |
| W [ mm ] | 16.3 |
| G [ qty. ] | 6 |
| S [ mm ] | M16x1.5 |
| Clockwise | CW |
OE Number (31)
| OE Number | Producer |
|---|---|
| 2606436 | VALEO |
| TG12C079 | VALEO |
| TG12C122 | VALEO |
| FG15T052 | VALEO |
| FG15T074 | VALEO |
| Y665-18-300A | MAZDA |
| Y665-18-300B | MAZDA |
| 1704768 | FORD |
| 1762377 | FORD |
| 1873207 | FORD |
| 2051880 | FORD |
| 2251619 | FORD |
| AV6Q-10A352-BA | FORD |
| AV6N-10300-DA | FORD |
| AV6N-10300-DB | FORD |
| AV6N-10300-DC | FORD |
| AV6N-10300-DD | FORD |
| AV6N-10300-MB | FORD |
| AV6N-10300-MC | FORD |
| AV6N-10300-MD | FORD |
| ET76-10300-AA | FORD |
| 30659389 | VOLVO |
| 30659701 | VOLVO |
| 31285658 | VOLVO |
| 36001116 | VOLVO |
| 36001502 | VOLVO |
| 36001971 | VOLVO |
| 20213 | LESTER |
| LRA03431 | LUCAS |
| AV6Q10A352BA | FORD |
| 595441 | VALEO |
| Application | Brand |
|---|---|
| B-MAX (JK),1.5 TDCi,1.6 TDCi , 2004-2015 | FORD |
| B-MAX Van (JK),1.5 TDCi, 2004-2015 | FORD |
| C-MAX II (DXA/CB7, DXA/CEU),1.5 TDCi,1.5 TDCi ECOnetic,1.6 TDCi,2.0 TDCi, 2002-2015 | FORD |
| C-MAX II Van,1.5 TDCi,1.5 TDCi ECOnetic,2.0 TDCi | FORD |
| ECOSPORT,1.5 TDCi, 2005-2015 | FORD |
| FIESTA VI(CB1,CCN),1.4 TDC,1.5 TDCi,1.6 TDCi, 2001-2015 | FORD |
| FIESTA VI Van,1.4TDC,1.5 TDCi,1.6TDCi, 2001-2015 | FORD |
| FOCUS II Saloon (DB,FCH, DH),2.0TDCi, 2002-2012 | FORD |
| FOCUS III,1.5 TDCi,1.5 TDCi ECOnetic, 1.6 TDCi,1.6 TDCi ECOnetic,2.0 TDCi,2.0 TDCi ST, 2005-2014 | FORD |
| FOCUS III Box Body / Estate,1.5 TDCi,1.5 TDCi ECOnetic,2.0 TDCi, 2009-2014 | FORD |
| FOCUS III Saloon,1.5 TDCi,1.5 TDCi ECOnetic,1.6T DCi,2.0 TDCi, 2007-2014 | FORD |
| FOCUS III Turnier,1.5 TDCi,1.5 TDCi ECOnetic,1.6 TDCi,1.6 TDCi ECOnetic,2.0 TDCi,2.0 TDCi ST, 2005-2014 | FORD |
| GRAND C-MAX (DXA/CB7, DXA/CEU), 1.5 TDCi,1.6 TDCi,2.0 TDCi, 2002-2015 | FORD |
| GRAND C-MAX Van,1.5 TDCi,1.6 TDCi,2.0 TDCi, 2002-2015 | FORD |
| KUGA II (DM2), 2.0 TDCi,2.0 TDCi 4x4, 2003-2014 | FORD |
| KUGA II Van,2.0 TDCi,2.0 TDCi 4x4, 2009-2014 | FORD |
| TOURNEO CONNECT / GRAND TOURNEO CONNECT Kombi, 1.5 TDCi,1.6 TDCi, 2005-2015 | FORD |
| TOURNEO COURIER B460 Kombi,1.5 TDCi,1.6 TDCi, 2002-2015 | FORD |
| TRANSIT CONNECT Box, 1.5 TDCi,1.6 TDCi, 2002-2015 | FORD |
| TRANSIT CONNECT Estate, 1.5 TDCi,1.6 TDCi, 2002-2015 | FORD |
| TRANSIT COURIER V408 Box, 1.5 TDCi,1.6 TDCi, 2002-2015 | FORD |
| TRANSIT COURIER B460 Box,1.5 TDCi,1.6 TDCi, 2002-2015 | FORD |
| TRANSIT COURIER B460 Kombi,1.5 TDCi,1.6 TDCi, 2002-2015 | FORD |
| Application | Brand |
|---|---|
| 2 (DE, DH3), 1.4 MZR-CD 1.6 MZ-CD 01/15 | MAZDA |
| Application | Brand |
|---|---|
| C30 (533), 1.6 D2 , 2010-2012 | VOLVO |
| S40 II (544), 1.6 D2 , 2010-2012 | VOLVO |
| V50 (545), 1.6 D2 , 2001-2012 | VOLVO |
Frequently Asked Questions about HM-1170
Q: What OE numbers does HM-1170 replace?
A: The HM-1170 is a direct replacement for: VALEO 2606436, VALEO TG12C079, VALEO TG12C122, VALEO FG15T052, VALEO FG15T074, MAZDA Y665-18-300A.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: LUK-LITENS 535023610, LITENS 700006, LITENS 920006, CARGO 333426, DAYCO ALP2462, IKA 354451.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
