HM-1190
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 53.4 |
| L [ mm ] | 43.5 |
| W [ mm ] | 13 |
| G [ qty. ] | 6 |
| S [ mm ] | M16x1.5 |
| Clockwise | CW |
OE Number (44)
| OE Number | Producer |
|---|---|
| 2607423 | VALEO |
| 1678607 | FORD |
| 1678608 | FORD |
| 1684713 | FORD |
| 1685793 | FORD |
| 1704769 | FORD |
| 1707065 | FORD |
| 1711969 | FORD |
| 2032603 | FORD |
| AG9T-10300-AA | FORD |
| AG9T-10300-BA | FORD |
| AG9T-10300-CA | FORD |
| AG9T-10300-DA | FORD |
| AV6Q-10A352-AA | FORD |
| AV6Q-10A352-AB | FORD |
| AV6N-10300-GB | FORD |
| AV6N-10300-GC | FORD |
| AV6N-10300-GD | FORD |
| Y666-18-300A | MAZDA |
| Y666-18-300B | MAZDA |
| Y666-18-300C | MAZDA |
| FG18T058 | VALEO |
| TG15C169 | VALEO |
| TG15C174 | VALEO |
| TG15C183 | VALEO |
| TG15C186 | VALEO |
| 30285659 | VOLVO |
| 30419219 | VOLVO |
| 30644799 | VOLVO |
| 30659390 | VOLVO |
| 31266149 | VOLVO |
| 31285399 | VOLVO |
| 31285659 | VOLVO |
| 31285815 | VOLVO |
| 36001104 | VOLVO |
| 36001117 | VOLVO |
| 36001501 | VOLVO |
| 36002929 | VOLVO |
| 36012505 | VOLVO |
| 20214 | LESTER |
| 20716 | LESTER |
| LRA03555 | LUCAS |
| LRA03885 | LUCAS |
| AV6Q10A352AA | FORD |
| Application | Brand |
|---|---|
| B-MAX (JK), 1.5 TDCi ,1.6 TDCi , 2004-2015 | FORD |
| B-MAX Van (JK),1.5 TDCi ,1.6TDCi, 2004-2015 | FORD |
| C-MAX (DM2),1.6 TDCi , 2002-2010 | FORD |
| C-MAX II Van,1.5 TDCi,1.5 TDCi ECOnetic, 1.6 TDCi | FORD |
| ECOSPORT,1.5 TDCi, 2005-2015 | FORD |
| FIESTA VI(CB1,CCN),1.4 TDCi,1.6 TDCi, 2001-2010 | FORD |
| FIESTA VI Van,1.4 TDCi,1.6 TDCi, 2001-2010 | FORD |
| FOCUS III Box Body/Hatchback,1.5 TDCi,1.5 TDCi ECOnetic,1.6 TDCi, 2001-2012 | FORD |
| FOCUS III Box Body/Estate,1.5 TDCi,1.5 TDCi ECOnetic, 2009-2014 | FORD |
| FOCUS III Saloon,1.5 TDCi,1.5 TDCi ECOnetic,1.6 TDCi,2.0 TDCi, 2005-2014 | FORD |
| FOCUS III Turnier,1.5 TDCi,1.5 TDCi ECOnetic,1.6 TDCi,2.0 TDCi, 2005-2014 | FORD |
| GALAXY (WA6),1.6 TDCi,2.0 TDCi, 2002-2015 | FORD |
| GRAND C-MAX (DXA/CB7, DXA/CEU), 1.5 TDCi,1.6 TDCi,2.0 TDCi , 2002-2015 | FORD |
| GRAND C-MAX Van,1.5 TDCi,1.6 TDCi, 2003-2015 | FORD |
| KUGA II (DM2),1.5 TDCi,2.0 TDCi,2.0 TDCi 4x4, 2003-2016 | FORD |
| KUGA II VAN,2.0 TDCi,2.0 TDCi 4x4, 2009-2014 | FORD |
| MONDEO IV (BA7),1.6 TDCi,2.0 TDCi, 2001-2015 | FORD |
| MONDEO IV Saloon (BA7),1.6 TDCi,2.0 TDCi , 2001-2015 | FORD |
| MONDEO IV Turnier (BA7),1.6 TDCi,2.0 TDCi , 2001-2015 | FORD |
| MONDEO IV Van,2.0 TDCi, 2003-2014 | FORD |
| S-MAX (WA6),1.6 TDCi,2.0 TDCi, 2002-2014 | FORD |
| TOURNEO COURIER B460 Kombi,1.5 EcoBlue,1.5 TDCi | FORD |
| TRANSIT CONNECT Estate,1.5 TDCi,1.6 TDCi, 2002-2015 | FORD |
| TRANSIT CONNECT V408 Box,1.5 TDCi, 1.6 TDCi, 2002-2015 | FORD |
| TRANSIT COURIER B460 Box,1.5 EcoBlue,1.5 TDCi, 1.6 TDCi, 2002-2018 | FORD |
| TRANSIT COURIER B460 Kombi,1.5 EcoBlue,1.5 TDCi, 1.6 TDCi, 2002-2018 | FORD |
| Application | Brand |
|---|---|
| 2 (DE, DH3),1.4 MZR-CD,1.6 MZ-CD, 2001-2015 | MAZDA |
| 3 (BL),1.6 MZ-CD,1.6 MZR-CD, 05/13 Saloon (BL), 1.6 MZR CD, 2005-2013 | MAZDA |
| 5 (CW),1.6 CD, 2009-2010 | MAZDA |
| Application | Brand |
|---|---|
| C30 (533),1.6 D2, 2010-2012 | VOLVO |
| S40 II (544), 1.6 D2, 2010-2012 | VOLVO |
| S60 II (134),DRIVe / D2, 2001-2015 | VOLVO |
| S80 II (124),1.6 DRIVe,1.6 D DRIVe,1.6 D2, 2001-2014 | VOLVO |
| V40 Box Body / Hatchback (525, 526), 1.6 D2/ DRIVe | VOLVO |
| V40 Hatchback (525, 526), D2, 2003-2012 | VOLVO |
| V50 (545), 1.6 D2, 2001-2012 | VOLVO |
| V60 Box Body/Estate (155),1.6 DRIVe, 2009-2015 | VOLVO |
| V60 I (155, 157), 1.6 DRIVe, 2002-2015 | VOLVO |
| V70 III (135), 1.6 D,1.6 DRIVe, 2004-2015 | VOLVO |
Reference number (14)
| Ref Number | Producer |
|---|---|
| 535023710 | LUK-LITENS |
| 920007 | LITENS |
| 333427 | CARGO |
| ALP2465 | DAYCO |
| 354461 | IKA |
| 79010008 | LESTER |
| 24-94281 | WAI |
| 28798C/A | ZNP |
| 21547 | JIASUN |
| 80328 | NF |
| AFP3029 | AS |
| UD13311AFP | AS |
| F032333427 | HC-CARGO |
| AFP3029LITENS | AS |
Frequently Asked Questions about HM-1190
Q: What OE numbers does HM-1190 replace?
A: The HM-1190 is a direct replacement for: VALEO 2607423, FORD 1678607, FORD 1678608, FORD 1684713, FORD 1685793, FORD 1704769.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: LUK-LITENS 535023710, LITENS 920007, CARGO 333427, DAYCO ALP2465, IKA 354461, LESTER 79010008.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
