HM-3028
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 59.7 |
| L [ mm ] | 34.5 |
| W [ mm ] | 6.2 |
| G [ qty. ] | 5 |
| S [ mm ] | M16x1.5 |
| Clockwise | CW |
OE Number (30)
| OE Number | Producer |
|---|---|
| 23152 | LESTER |
| 23153 | LESTER |
| 23203 | LESTER |
| LRA02813 | LUCAS |
| JA1709IR | CARGO |
| AF111225 | VALEO |
| AF111390 | VALEO |
| TA000A56901 | VALEO |
| TA000A61201 | VALEO |
| 02131-9070 | DENSO |
| OK554-18W11 | HYUNDAI |
| OK588-18W11 | HYUNDAI |
| 37300-4X000 | HYUNDAI |
| 37300-4X003 | HYUNDAI |
| 37300-4X220 | HYUNDAI |
| 37300-4X500 | HYUNDAI |
| 37300-4X501 | HYUNDAI |
| 37300-4X502 | HYUNDAI |
| 37300-4X503 | HYUNDAI |
| 37300-4X950 | HYUNDAI |
| 37321-4X210 | HYUNDAI |
| 37321-4X300 | HYUNDAI |
| 37321-4X301 | HYUNDAI |
| 37322-4X000 | HYUNDAI |
| OK552-18300-B | KIA |
| OK553-18300-A | KIA |
| OK554-18300 | KIA |
| OK554-18300-A | KIA |
| 720110740 | POONGSUNG |
| EC4237 | WOOD AUTO SUPPL |
Reference number (33)
| Ref Number | Producer |
|---|---|
| F-231618 | INA |
| F-231618.01 | INA |
| F-231618.02 | INA |
| F-231618.04 | INA |
| F-261618.05 | INA |
| 535003410 | LUK |
| 230527 | CARGO |
| 333335 | CARGO |
| ALP2428 | DAYCO |
| 335561 | IKA |
| 79033035 | LESTER |
| 5466 | ZEN |
| 24-89250 | WAI |
| 28608 | ZNP |
| 21466 | JIASUN |
| 80129 | NF |
| 588073 | VALEO |
| 2655702 | VALEO |
| K406700 | VALEO |
| 72011-0740 | DENSO |
| F032230527 | HC-CARGO |
| AFP1001 | AS |
| AFP1001INA | AS |
| AFP1001V | AS |
| F21361801 | INA |
| F2136181 | INA |
| F23161801 | INA |
| F23161802 | INA |
| F23161804 | INA |
| F23161805 | INA |
| F2316181 | INA |
| F2316185 | INA |
| 5350034000 | LUK |
Frequently Asked Questions about HM-3028
Q: What OE numbers does HM-3028 replace?
A: The HM-3028 is a direct replacement for: LESTER 23152, LESTER 23153, LESTER 23203, LUCAS LRA02813, CARGO JA1709IR, VALEO AF111225.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: INA F-231618, INA F-231618.01, INA F-231618.02, INA F-231618.04, INA F-261618.05, LUK 535003410.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
