HM-3031
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 55.6 |
| L [ mm ] | 34.5 |
| W [ mm ] | 10.7 |
| G [ qty. ] | 5 |
| S [ mm ] | M16x1.5 |
| Clockwise | CW |
OE Number (25)
| OE Number | Producer |
|---|---|
| 121615014 | BOSCH |
| 121615114 | BOSCH |
| 121711014 | BOSCH |
| 125711014 | BOSCH |
| 125711023 | BOSCH |
| 125711040 | BOSCH |
| 125711048 | BOSCH |
| 125711053 | BOSCH |
| 986080810 | BOSCH |
| F00E100026 | BOSCH |
| 1541451 | FORD |
| 2099471 | FORD |
| 6M5J-10300-SA | FORD |
| 6M5T-10300-SA | FORD |
| AM5T-10300-SA | FORD |
| LRA03098 | LUCAS |
| 11347 | LESTER |
| 30667980 | VOLVO |
| 30773111 | VOLVO |
| 31288879 | VOLVO |
| 31288880 | VOLVO |
| 36000207 | VOLVO |
| 36000613 | VOLVO |
| 36001497 | VOLVO |
| 353850 | JAHN |
| Application | Brand |
|---|---|
| KUGA I, 2.5,2.5 4x4 , 2002-2012 | Ford |
| Application | Brand |
|---|---|
| C30 (533),2.4 i,D3,D4,D5,T5, 2003-2012 | Volvo |
| C70 II Convertible (542),2.4,2.4 D,2.4 i,D3,D4,D5,T5, 2003-2013 | Volvo |
| S40 II (544), D3,2.4,2.4 CDI,2.4 D5,D4,T5,T5 AWD | Volvo |
| V40 Box Body / Hatchback (525, 526), 2.0 D3,2.0 D4 | Volvo |
| V40 Hatchback (525, 526),D3,D4,T4,T4 AWD ,T5,T5 AWD, 2001-2015 | Volvo |
| V50 (545),2.4,2.4 AWD,2.4 D5,2.4 Tdi,D3,D4,T5,T5 AWD 2003-2012 | Volvo |
Reference number (25)
| Ref Number | Producer |
|---|---|
| F-557564.XX | INA |
| 535016110 | LUK |
| 331651 | CARGO |
| ALP2441 | DAYCO |
| 353851 | IKA |
| 79201034 | LESTER |
| 24-912101 | WAI |
| 24-91329 | WAI |
| 28742 | ZNP |
| 80348 | NF |
| AFP0067 | AS |
| UD13255AFP | AS |
| F00M349823 | BOSCH |
| F00M391124 | BOSCH |
| F032335277 | HC-CARGO |
| F032331651 | HC-CARGO |
| 335277 | HC-CARGO |
| F557564 | INA |
| 5350161000 | LUK |
| 535016100 | LUK |
| 5350161010 | LUK |
| 2491329 | WAI |
| 5668 | ZEN |
| AFP0067INA | AS |
| F557565 | INA |
Frequently Asked Questions about HM-3031
Q: What OE numbers does HM-3031 replace?
A: The HM-3031 is a direct replacement for: BOSCH 121615014, BOSCH 121615114, BOSCH 121711014, BOSCH 125711014, BOSCH 125711023, BOSCH 125711040.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: INA F-557564.XX, LUK 535016110, CARGO 331651, DAYCO ALP2441, IKA 353851, LESTER 79201034.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
