HM-1211
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 59.08 |
| L [ mm ] | 45.4 |
| W [ mm ] | 9.1 |
| G [ qty. ] | 6 |
| S [ mm ] | M14x1.5 |
| Clockwise | CW |
OE Number (9)
| OE Number | Producer |
|---|---|
| 104210-6870 | DENSO |
| 104211-8360 | DENSO |
| TN104210-6870 | DENSO |
| TN104210-6871 | DENSO |
| TN104211-8360 | DENSO |
| 22868687 | GM |
| 22949467 | GM |
| 11794 | LESTER |
| 14009 | LESTER |
| Application | Brand |
|---|---|
| ESCALADE 6.2 AWD L86 09.2014 - 12.2020 | CADILLAC |
| CTS 6.2 V LT4(376CUV8) 04.2015 - | CADILLAC |
| Application | Brand |
|---|---|
| SILVERADO 1500 Crew Cab Pickup 5.3 4WD L83(325CUV8) 07.2014 - | CHEVROLET |
| SILVERADO 1500 Standard Cab Pickup 5.3 4WD L83(325CUV8) 07.2014 - | CHEVROLET |
| SILVERADO 1500 Extended Cab Pickup 5.3 4WD L83(325CUV8) 07.2014 - 12.2019 | CHEVROLET |
| CAMARO 6.2 LT1(376CUV8) 06.2016 - | CHEVROLET |
Reference number (5)
| Ref Number | Producer |
|---|---|
| 920031 | LITENS |
| 24-82331-4 | WAI |
| 28917 | ZNP |
| 12645462 | GM |
| 79909133 | LESTER |
Frequently Asked Questions about HM-1211
Q: What OE numbers does HM-1211 replace?
A: The HM-1211 is a direct replacement for: DENSO 104210-6870, DENSO 104211-8360, DENSO TN104210-6870, DENSO TN104210-6871, DENSO TN104211-8360, GM 22868687.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: LITENS 920031, WAI 24-82331-4, ZNP 28917, GM 12645462, LESTER 79909133.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
