HM-1296
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 58 |
| L [ mm ] | 41.6 |
| W [ mm ] | 11 |
| G [ qty. ] | 6 |
| S [ mm ] | M14x1.5 |
| Clockwise | CW |
OE Number (12)
| OE Number | Producer |
|---|---|
| LRA03563 | LUCAS |
| 104211-3000 | DENSO |
| 104211-3001 | DENSO |
| 104211-3002 | DENSO |
| 104211-3103 | DENSO |
| 27060-0N090 | TOYOTA/LEXUS |
| 27060-0N100 | TOYOTA/LEXUS |
| 27060-0N110 | TOYOTA/LEXUS |
| 27060-0N120 | TOYOTA/LEXUS |
| 27060-0N130 | TOYOTA/LEXUS |
| 27060-0N140 | TOYOTA/LEXUS |
| 27415-33100 | TOYOTA/LEXUS |
| Application | Brand |
|---|---|
| AURIS (E18), 1.4 D-4D (NDE180), 2010-2018 | TOYOTA |
| AURIS Estate (E18),1.4 D-4D (NDE180)£¬2007-2018 | TOYOTA |
| AURIS VAN Box (E18),1.4 D-4D (NDE180)£¬2003-2018 | TOYOTA |
| COROLLA Saloon (E18, ZRE1), 1.4 D-4D (NDE180,NDE170)£¬2001-2018 | TOYOTA |
| YARIS (P13), 1.4 D (NLP130), 2009-2012 | TOYOTA |
Frequently Asked Questions about HM-1296
Q: What OE numbers does HM-1296 replace?
A: The HM-1296 is a direct replacement for: LUCAS LRA03563, DENSO 104211-3000, DENSO 104211-3001, DENSO 104211-3002, DENSO 104211-3103, TOYOTA/LEXUS 27060-0N090.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: INA F-621236.01, LUK 535030310, ZEN 5794, RUVILLE 56954, ZNP 28862, NTN 374V1-1.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
