HM-2003
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 59.6 |
| L [ mm ] | 40.1 |
| W [ mm ] | 8 |
| G [ qty. ] | 7 |
| S [ mm ] | M16x1.5 |
| Clockwise | CW |
OE Number (47)
| OE Number | Producer |
|---|---|
| 104210-4880 | DENSO |
| 986049800 | BOSCH |
| 125811059 | BOSCH |
| 125811060 | BOSCH |
| 93196797 | GM |
| 93196984 | GM |
| 95514576 | GM |
| CD215541 | HITACHI |
| GD215541 | HITACHI |
| GD215541-1 | HITACHI |
| LR1130702 | HITACHI |
| LR160745-B | HITACHI |
| LR190745 | HITACHI |
| LR190752 | HITACHI |
| 23100-2W201 | NISSAN |
| 23100-5S900 | NISSAN |
| 23100-5S90A | NISSAN |
| 23100-5S90B | NISSAN |
| 23100-5S90C | NISSAN |
| 23100-DB000 | NISSAN |
| 23100-DB00A | NISSAN |
| 23100-DB00B | NISSAN |
| 23100-VC100 | NISSAN |
| 23100-VC101 | NISSAN |
| 23100-VC10A | NISSAN |
| 23100-VC10B | NISSAN |
| 23100-VC10C | NISSAN |
| 23100-VC201 | NISSAN |
| 23100-VG100 | NISSAN |
| 23150-2W200 | NISSAN |
| 23150-2W20A | NISSAN |
| 23150-2W20B | NISSAN |
| 23100-A084A | DFAC |
| 4406495 | OPEL |
| 4419036 | OPEL |
| 4419088 | OPEL |
| 23100-8255R | RENAULT |
| 5010437730 | RENAULT |
| 5010553879 | RENAULT |
| 7701070077 | RENAULT |
| 23215 | LESTER |
| LRA02873 | LUCAS |
| LRA02215 | LUCAS |
| 231502W200 | NISSAN |
| 231502W20A | NISSAN |
| L170G25003 | HITACHI |
| EC4227 | WOOD AUTO SUPPL |
| Application | Brand |
|---|---|
| INTERSTAR Box (X70),dCi 140 , 2003-2011 | NISSAN |
| INTERSTAR Bus (X70),dCi 140 , 2003-2011 | NISSAN |
| INTERSTAR Platform/Chassis,dCi 140, 2003-2011 | NISSAN |
| PATROL GR V Platform/Chassis (Y61),3.0 D 4x4 (TY61) , 2007-2009 | NISSAN |
| PATROL GR V Wagon (Y61),3.0 DTi, 2000-2005 | NISSAN |
| TERRANO II (R20), 3.0 Di 4WD, 2002-2009 | NISSAN |
| TERRANO II Van (R20),3.0 Di 4WD, 2003-2009 | NISSAN |
| Application | Brand |
|---|---|
| MOVANO Box (X70),3.0 DTI (FD), 2003-2010 | OPEL |
| MOVANO Combi (X70),3.0 DTI(JD), 2003-2010 | OPEL |
| MOVANO Dumptruck (X70),3.0 DTI (ED, HD, UD0, UD4) | OPEL |
| MOVANO Platform/Chassis (X70),3.0 DTI (ED, HD, UD0,UD4), 2003-2010 | OPEL |
| Application | Brand |
|---|---|
| MASTER II Box (FD), 3.0 dCi , 2003-2010 | RENAULT |
| MASTER II Bus (JD),3.0 dCi , 2003-2010 | RENAULT |
| MASTER II Platform/Chassis (ED/HD/UD),3.0 dCi , 2003-2010 | RENAULT |
| Application | Brand |
|---|---|
| MASCOTT Box Body / Estate, 120.55,160.35, 160.55 | RENAULT TRUCKS |
| Application | Brand |
|---|---|
| Platform/Chassis,120.35,120.55,120.65,160.35,160.55,160.65, 2004-2012 | MASCOTT |
| Application | Brand |
|---|---|
| MOVANO Mk I (A) Chassis/Cab (X70),3.0 DTi (ED) | VAUXHALL |
| MOVANO Mk I (A) Combi (X70),3.0 DTi (JD) , 2003-2010 | VAUXHALL |
| MOVANO Mk I (A) Van (X70),3.0 DTi(FD), 2003-2010 | VAUXHALL |
Reference number (29)
| Ref Number | Producer |
|---|---|
| F-228751.XX | INA |
| 535005310 | LUK |
| 230521 | CARGO |
| 332299 | CARGO |
| ALP2356 | DAYCO |
| 335281 | IKA |
| 79044017 | LESTER |
| 5431 | ZEN |
| 24-81109-3 | WAI |
| 28639 | ZNP |
| 21431 | JIASUN |
| 80077 | NF |
| AFP2003 | AS |
| UD13282AFP | AS |
| 588079 | VALEO |
| F00M591130 | BOSCH |
| F00M599806 | BOSCH |
| F032332299 | HC-CARGO |
| F032230521 | HC-CARGO |
| F22875103 | INA |
| F22875106 | INA |
| F22875107 | INA |
| F2287512 | INA |
| F2287513 | INA |
| 5350053000 | LUK |
| AFP2003INA | AS |
| AFP2003V | AS |
| F22875102 | INA |
| F228751 | INA |
Frequently Asked Questions about HM-2003
Q: What OE numbers does HM-2003 replace?
A: The HM-2003 is a direct replacement for: DENSO 104210-4880, BOSCH 986049800, BOSCH 125811059, BOSCH 125811060, GM 93196797, GM 93196984.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: INA F-228751.XX, LUK 535005310, CARGO 230521, CARGO 332299, DAYCO ALP2356, IKA 335281.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
