HM-2019
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 55 |
| L [ mm ] | 50.2 |
| W [ mm ] | 9 |
| G [ qty. ] | 7 |
| S [ mm ] | M14x1.5 |
| Clockwise | CW |
OE Number (37)
| OE Number | Producer |
|---|---|
| 11088 | LESTER |
| 11201 | LESTER |
| LRA02996 | LUCAS |
| 104210-3780 | DENSO |
| 104210-4660 | DENSO |
| 104210-4661 | DENSO |
| 104210-4662 | DENSO |
| 104210-4663 | DENSO |
| 104210-4790 | DENSO |
| 104210-4810 | DENSO |
| 104210-4811 | DENSO |
| 104210-4881 | DENSO |
| 104210-2590 | DENSO |
| 104210-4980 | DENSO |
| 104210-4982 | DENSO |
| 27060-0H110 | TOYOTA |
| 27060-0H111 | TOYOTA |
| 27060-0H230 | TOYOTA |
| 27060-28300 | TOYOTA |
| 27060-28301 | TOYOTA |
| 27060-28310 | TOYOTA |
| 27060-28311 | TOYOTA |
| 27060-28320 | TOYOTA |
| 27060-28321 | TOYOTA |
| 27060-28340 | TOYOTA |
| 27060-28341 | TOYOTA |
| 27060-28360 | TOYOTA |
| 27060-28361 | TOYOTA |
| 27060-28370 | TOYOTA |
| 27060-28380 | TOYOTA |
| 27415-0W040 | TOYOTA |
| 27415-0W041 | TOYOTA |
| 27415-0W042 | TOYOTA |
| 19205069 | PONTIAC |
| 88975511 | PONTIAC |
| 274150W040 | TOYOTA |
| 0210401550 | DENSO |
| Application | Brand |
|---|---|
| ES (V4),240 (ACV40), 2006-2012 | LEXUS |
| Application | Brand |
|---|---|
| VIBE Estate,2.4,2.4 AWD, 2008-2012 | PONTIAC |
| Application | Brand |
|---|---|
| ALPHARD (H1),2.4,2.4 4WD, 2003-2009 | TOYOTA |
| ALPHARD / VELLFIRE (H2), 2.4,2.4 4WD, 2004-2014 | TOYOTA |
| AURION (V4),2.4, 2003-2009 | TOYOTA |
| CAMRY Saloon (V3),2.4 , 2001-2011 | TOYOTA |
| CAMRY Saloon (V4),2.4,2.4 Hybrid, 2001-2011 | TOYOTA |
| CAMRY Saloon (V5),2.0 (ACV51) 2.0, 2009-2011 | TOYOTA |
| COROLLA RUMION (E15),2.4, 2005-2015 | TOYOTA |
| COROLLA Saloon (E15),2.4, 2001-2014 | TOYOTA |
| MATRIX (E14), 2.4,2.4 4WD, 2001-2014 | TOYOTA |
| PREVIA (R3), 2.4, 2000-2006 | TOYOTA |
| PREVIA III (R2, R5),2.4, 2005-2010 | TOYOTA |
| RAV 4 II (A2),2.4 4WD, 2003-2011 | TOYOTA |
| RAV 4 III (A3),2.4,2.4 4WD, 2005-2013 | TOYOTA |
| SOLARA Coupe (V3),2.4, 2003-2011 | TOYOTA |
| Application | Brand |
|---|---|
| CAMRY (V5),2.0, 2011-2015 | TOYOTA (GAC) |
| MARK X ZiO (A1), 2.4,2.4 4WD | TOYOTA (GAC) |
Reference number (23)
| Ref Number | Producer |
|---|---|
| 535019810 | LUK-LITENS |
| 920802 | LITENS |
| 600802 | LITENS |
| 330850 | CARGO |
| 333454 | CARGO |
| ALP2397 | DAYCO |
| 353781 | IKA |
| 79909050 | LESTER |
| 5502 | ZEN |
| 24-82291-4 | WAI |
| 28696A | ZNP |
| 21502 | JIASUN |
| 80065 | NF |
| AFP6074S | AS |
| 27415-0W040A | TOYOTA |
| 27415-0W040B | TOYOTA |
| 27415-0W040C | TOYOTA |
| 80119 | NF |
| AFP6114S | AS |
| F032333454 | HC-CARGO |
| F032330850 | HC-CARGO |
| 24822914 | WAI |
| AFP6014LITENS | AS |
Frequently Asked Questions about HM-2019
Q: What OE numbers does HM-2019 replace?
A: The HM-2019 is a direct replacement for: LESTER 11088, LESTER 11201, LUCAS LRA02996, DENSO 104210-3780, DENSO 104210-4660, DENSO 104210-4661.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: LUK-LITENS 535019810, LITENS 920802, LITENS 600802, CARGO 330850, CARGO 333454, DAYCO ALP2397.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
