HM-3038
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 59.7 |
| L [ mm ] | 39.3 |
| W [ mm ] | 9.1 |
| G [ qty. ] | 8 |
| S [ mm ] | M17x1.5 |
| Clockwise | CW |
OE Number (23)
| OE Number | Producer |
|---|---|
| R2AA-18-300A | MAZDA |
| R2AA-18-300B | MAZDA |
| RF5C-18-300 | MAZDA |
| RF5C-18-300A | MAZDA |
| RF5C-18-330 | MAZDA |
| RF5C-18-330A | MAZDA |
| RF5C-18-W11 | MAZDA |
| RF7J-18-300A | MAZDA |
| RF7J-18-300B | MAZDA |
| RF8G-18-300 | MAZDA |
| RF8G-18-300A | MAZDA |
| A628X92071 | MITSUBISHI |
| A2TJ0681A | MITSUBISHI |
| A3TB4981 | MITSUBISHI |
| A3TB6581 | MITSUBISHI |
| A3TB6781 | MITSUBISHI |
| CA1972IR | CARGO |
| 11836 | LESTER |
| 23309 | LESTER |
| 23945 | LESTER |
| LRA02309 | LUCAS |
| RF5C18330 | MAZDA |
| F236001 | MITSUBISHI |
| Application | Brand |
|---|---|
| 3 (BK),2.0 MZR CD, 2006-2009 | Mazda |
| 3 (BL),2.2 MZR CD, 2001-2013 | Mazda |
| 3 Saloon (BK),2.0 MZR-CD, 2006-2012 | Mazda |
| 3 Saloon (BL),2.2 MZR CD, 2001-2014 | Mazda |
| 5 (CR19), 2.0 CD, 2002-2010 | Mazda |
| 5 (CW), 1.6 CD, 2009-2010 | Mazda |
| 6 Estate (GH),2.0 MZR-CD,2.2 D,2.2 MZR-CD, 2001-2013 | Mazda |
| 6 Hatchback (GG),2.0 DI, 2002-2008 | Mazda |
| 6 Hatchback(GH),2.0 MZR-CD,2.2 D,2.2 MZR-CD, 2001-2012 | Mazda |
| 6 Saloon (GG), 2.0 DI, 2002-2008 | Mazda |
| 6 Saloon (GH),2.0 MZR-CD,2.2 D,2.2 MZR-CD, 2001-2013 | Mazda |
| 6 Station Wagon (GY),2.0 DI, 2002-2008 | Mazda |
| CX-7 (ER),2.2 MZR-CD AWD, 2001-2013 | Mazda |
Reference number (21)
| Ref Number | Producer |
|---|---|
| F-236001.XX | INA |
| 535004910 | LUK |
| 238068 | CARGO |
| 332313 | CARGO |
| ALP2372 | DAYCO |
| 353531 | IKA |
| 79032284 | LESTER |
| 5527 | ZEN |
| 24-83276 | WAI |
| 28703 | ZNP |
| 21643 | JIASUN |
| 80229 | NF |
| AFP5004 | AS |
| UD13325AFP | AS |
| 588053 | VALEO |
| F032332313 | HC-CARGO |
| F032238068 | HC-CARGO |
| AFP5004INA | AS |
| AFP5004V | AS |
| F23600101 | INA |
| F23600102 | INA |
Frequently Asked Questions about HM-3038
Q: What OE numbers does HM-3038 replace?
A: The HM-3038 is a direct replacement for: MAZDA R2AA-18-300A, MAZDA R2AA-18-300B, MAZDA RF5C-18-300, MAZDA RF5C-18-300A, MAZDA RF5C-18-330, MAZDA RF5C-18-330A.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: INA F-236001.XX, LUK 535004910, CARGO 238068, CARGO 332313, DAYCO ALP2372, IKA 353531.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
