HM-3122
📐 Technical Specifications
| I.D [ mm ] | 17 |
|---|---|
| O.D [ mm ] | 59.3 |
| L [ mm ] | 48.5 |
| W [ mm ] | 16 |
| G [ qty. ] | 8 |
| S [ mm ] | M16x1.5 |
| Clockwise | CW |
OE Number (2)
| OE Number | Producer |
|---|---|
| ADJA1153E 14V 150A | ANMEIDE |
| ADJA2083 28V 80A | ANMEIDE |
| Application | Brand |
|---|---|
| Dongfeng Duolika | Dongfeng |
| Dongfeng Captain | Dongfeng |
| Application | Brand |
|---|---|
| Futian Aumark | Futian |
| Futian Ouling | Futian |
| Futian Ruiwo | Futian |
| Futian Times | Futian |
| Futian Jingang | Futian |
| Application | Brand |
|---|---|
| JAC Shuailing | JAC |
| JAC Junling 2.2L China VI 2021- | JAC |
| JAC Kangling | JAC |
| JAC Weiling | JAC |
| JAC Haowei | JAC |
| JAC Haoyun | JAC |
| Application | Brand |
|---|---|
| Beyond | SAIC Yuejin |
| Beyond C | SAIC Yuejin |
| Shangjun | SAIC Yuejin |
| Shangjun X | SAIC Yuejin |
| Shuaihu | SAIC Yuejin |
| Xiaofuxing S | SAIC Yuejin |
| Application | Brand |
|---|---|
| Nanjing Iveco | Iveco |
Reference number (2)
| Ref Number | Producer |
|---|---|
| 1025120FD020 | GAICI |
| 1025100FD080 | JAC |
Frequently Asked Questions about HM-3122
Q: What OE numbers does HM-3122 replace?
A: The HM-3122 is a direct replacement for: ANMEIDE ADJA1153E 14V 150A, ANMEIDE ADJA2083 28V 80A.
Q: What are the cross-reference numbers?
A: It is compatible with these aftermarket parts: GAICI 1025120FD020, JAC 1025100FD080.
Q: Is this part reliable?
A: Yes, it is 100% brand new and tested to meet OEM standards.
